Camera

• Image Sensor
  1/2.8″ Progressive Scan CMOS
• Max. Resolution
  1920×1080
• Min. Illumination
  Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light
• Shutter Time
  1/3 s to 1/100,000 s
• Day & Night
  24/7 color imaging
• Angle Adjustments
  Pan: 0° to 360°,tilt: 0° to 180°,rotate: 0° to 360°

  Lens

• Lens Type
  Fixed focal lens, 4 and 6 mm optional
• Focal Length & FOV

  4 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 99°
  6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 63°

• Lens Mount
  M12
• Iris Type
  Fixed
• Aperture
  F1.0
• Depth Of Field

  4 mm: 2.1 m to ∞
  6 mm: 4.6 m to ∞

  DORI

• DORI

  4 mm, D: 56 m, O: 22 m, W: 11 m, I: 5 m
  6 mm, D: 82 m, O: 32 m, W: 16 m, I: 8 m

  Illuminator

• Supplement Light Type
  White Light
• Supplement Light Range
  Up to 50 m
• Smart Supplement Light
  Yes

  Video

• Main Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 720)
  60 Hz: 30 fps (1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (640 × 480, 640 × 360)
  60 Hz: 30 fps (640 × 480, 640 × 360)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264,
  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate
  32 Kbps to 8 Mbps
• H.264 Type
  Baseline Profile, Main Profile, High Profile
• H.265 Type
  Main Profile
• Bit Rate Control
  CBR,VBR
• Region Of Interest (ROI)
  1 fixed region(s) for main stream

  Audio

• Audio Type
  -U: Mono sound
• Environment Noise Filtering
  -U: Yes
• Audio Sampling Rate
  -U: 8 kHz/16 kHz
• Audio Compression
  -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio Bit Rate
  -U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps ( AAC-LC)

  Network

• Protocols
  TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
• Simultaneous Live View
  Up to 6 channels
• API
  Open Network Video Interface (Profile S, Profile T, Profile G (only -U model supports)),ISAPI,SDK
• User/Host

  Up to 32 users

  3 user levels: administrator, operator, and user

• Security
  Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• Client
  iVMS-4200,Hik-Connect
• Web Browser

  Plug-in required live view: IE 10, IE 11,
  Local service: Chrome 57.0+, Firefox 52.0+


• Wide Dynamic Range (WDR)
  Digital WDR
• SNR
  ≥ 52 dB
• Day/Night Switch
  Day,Night,Auto,Schedule
• Image Enhancement
  BLC,HLC,3D DNR
• Image Settings
  Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Privacy Mask
  4 programmable polygon privacy masks

  Interface

• Ethernet Interface
  1 RJ45 10M/100M self-adaptive Ethernet port
• On-Board Storage
  Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
• Built-In Microphone
  -U: Yes
• Reset Key
  -F: Yes

  Event

• Basic Event
  Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• Linkage
  Upload to FTP/memory card (-F), notify surveillance center, send email, trigger recording (-F), trigger capture

  General

• Power

  12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm coaxial power plug,
  PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5W

• Material
  Front cover: metal, body: plastic, bracket: metal
• Dimension
  83.7 mm × 80.7 mm × 205.6 mm (3.3″ × 3.2″ × 8.1″)
• Package Dimension
  260 mm × 125 mm × 125 mm (10.2″ × 4.9″ × 4.9″)
• Weight

  -L : Approx. 560 g (1.2 lb.), -LUF : Approx. 580 g (1.3 lb.)

• With Package Weight

  -L: Approx. 615 g (1.4 lb.), -LUF: Approx. 635 g (1.4 lb.)

  Storage Conditions

• -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup And Operating Conditions
  -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language
  English, Ukrainian
• General Function
  Heartbeat, anti-banding, mirror, password protection, password reset via email

• Approval
• YOU C

  FCC: 47 CFR Part 15, Subpart B,
  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
  RCM: AS/NZS CISPR 32: 2015,
  KC: KN32: 2015, KN35: 2015

• Safety

  UL: UL 62368-1,
  CB: IEC 62368-1: 2014+A11,
  CE-LVD: EN 62368-1: 2014/A11: 2017,
  BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Environment

  CE-RoHS: 2011/65/EU,
  WEEE: 2012/19/EU,
  Reach: Regulation (EC) No 1907/2006

  Protection

• IP67: IEC 60529-2013
