Camera

• Image Sensor 2 MP CMOS
• Max. Resolution 1920 (H) × 1080 (V)
• Min. Illumination 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s
• Day ＆ Night ICR
• Angle Adjustment Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
• Signal System PAL/NTSC

Lens

• Lens Type 2.8 mm, 3.6 mm fixed focal lens
• Focal Length ＆ FOV 2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118° 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°
• Lens Mount M12

Illuminator

• Supplement Light Type White Light,IR
• Supplement Light Range IR : Up to 25 m, White Light : Up to 20 m


• Image Settings Brightness, Sharpness, Smart IR

Frame Rate

• TVI: 1080P @ 30 fps, 1080P @ 25 fps
• AHD: 1080P @ 30 fps, 1080P @ 25 fps
• CVI: 1080P @ 30 fps, 1080P @ 25 fps
• CVBS: PAL/NTSC
• Day/Night Mode Auto/Color/BW (Black and White)
• Wide Dynamic Range (WDR) Digital WDR
• Image Enhancement DWDR/BLC/HLC/Global
• White Balance Auto/Manual
• AGC Yes
• Interface
• Video Output Switchable TVI/AHD/CVI/CVBS

General

• Material Plastic
• Dimension 138.8 mm × 60.9 mm × 57.9 mm (5.47" × 2.4 " × 2.3")
• Weight Approx. 155 g (0.34 lb.)
• Operating Condition -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) Communication HIKVISION-C
