| Product Model |
| Product ModelDS-D5A86RB/B3 |
| Display |
| Screen Size86 inch |
| BacklightDLED |
| Pixel Pitch0.164 (H) × 0.493 (V) mm |
| Resolution3840 × 2160 @60 Hz |
| Brightness400 cd/m² |
| Color Depth10 bit (8 bit + FRC) |
| Display Color1.07 B |
| Response Time5 ms |
| Panel TypeIPS |
| Contrast Ratio |
| 1200:1 (Static) |
| 15,000:1 (Dynamic) |
| Color Gamut72% NTSC (CIE1931) (Typ.) |
| Refresh Rate60 Hz |
| Viewing Angle178° (H)/178° (V) |
| Aspect Ratio16:9 |
| Surface Hardness |
| 9H (Pencil) |
| 7 (Mohs) |
| Surface GlassAnti-Glare Glass |
| Surface Haze25% Haze |
| Glass Bonding MethodZero Lamination |
| Display Area1895.04 (H) × 1065.96 (V) mm |
| Working Duration7 × 16 H |
| Transmittance88% ± 3 |
| Lifespan50,000 hours |
| Touch |
| TypeInfrared Touch Screen |
| Touch PointUp to 50-point multi-touch |
| Touch Response Time≤ 5 ms |
| Minimum Touch Object≥ 1.5 mm (≥ 90% touching area) |
| Touch Precision± 0.5 mm (≥ 90% touching area) |
| Touch Resolution32768 × 32768 |
| Built-in System |
| Operation SystemAndroid 14.0 |
| Memory8 GB |
| Built-in Storage128 GB |
| ProcessorQuad-core Cortex-A72 × 4（2.2 GHz）and quad-core Cortex-A53 × 4（1.8 GHz） |
| GPUMali-G52 MC3 |
| HDCP Version2.3 & 2.2 & 1.4 |
| Camera |
| PixelPixel 48 MP for Photos & 8 MP for Video |
| Camera FunctionSupports intelligent switching between Android system, OPS, and PC. |
| Field Angle93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical) |
| Distortion≤ 2.5% |
| Camera Resolution RatioUp to 4K |
| Microphone |
| SpecificationOmni-directional 8-array layout |
| Mic FunctionEcho reduction and smart noise-cancellation |
| Voice Distance12 m |
| Sampling Rate48 K |
| Mic Depth16 bit |
| Internal Function |
| LoudspeakerBuilt-in 2 × 20 W |
| BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4 |
| NFC |
| Supports card reader |
| 13.56 MHz, (ISO 14443A/ ISO 14443B) |
| Light SensorYes |
| Image Processing TechnologySupports 3D digital noise reduction, face detection, automatic white balance, automatic purple edge removal, and automatic defogging; supports shadow correction. |
| Audio Processing TechnologySupports dereverberation, adaptive noise reduction, adaptive non-stationary noise reduction, adaptive echo cancellation, automatic gain control, automatic electrical level control, sound source localization, digital beam forming, and speech detection. |
| Interface |
| Video & Audio Input |
| HDMI 2.1 TMDS × 3（Front × 1; Rear × 2; Supports HDCP 2.3 & 2.2 & 1.4; HDMI1 Supports CEC&ARC protocol） |
| Audio × 1（Rear） |
| Video & audio outputAudio × 1（Rear） |
| Control interface |
| TOUCH-USB 2.0 × 1（Front × 1） |
| TOUCH-USB 2.0 × 1（Rear × 1） |
| RS232 × 1（Rear） |
| Network Interface |
| LAN (1000 Mbps) × 2（Rear） |
| Wi-Fi AP & Station, 2.4 G/5 G |
| Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP |
| Data Transmission Interface |
| USB 3.0 × 2（Front × 2） |
| USB 2.0 × 2（Rear × 2） |
| Type-C × 1 (Front × 1：Supports USB 3.0, 15 W charging functions) |
| TF-Card Slot × 1（Rear × 1） |
| Power |
| Power Supply100 to 240 VAC, 50/60 Hz |
| Standby Consumption≤ 0.5 W |
| Average Consumption< 210 W |
| Working Environment |
| Working Temperature0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity10%~90% RH |
| General |
| VESA800 mm × 600 mm (4 × M8-25 mm) |
| AccessoryWall mount bracket, hook, user manual, touch writing pen, packing list, power cable, remote control. |
| Package Dimensions (W × H × D)2157.0 × 1345.0 × 223.0 mm |
| Net Weight52.5 ± 0.5 kg |
| Gross Weight72.93 ± 0.5 kg |
| Product Dimensions （With Wall Attachment）1957.04 mm × 1173.7 mm × 123.0 mm (W × H × D) |
| Product Dimensions （Without Wall Attachment）1957.04 mm × 1173.7 mm × 95.8 mm (W × H × D) |
