| Product Model |
| Product ModelDS-D5C86RB/B2L |
| Display |
| Screen Size86 inch |
| BacklightDLED |
| Pixel Pitch0.164 (H) × 0.493 (V) mm |
| Resolution3840 × 2160 @60 Hz |
| Brightness480 cd/m² (Typ.) |
| Color Depth10 bit (8 bit + FRC) |
| Display Color1.07 G |
| Response Time5 ms |
| Panel TypeVA |
| Contrast Ratio |
| 5000:1 (Static) |
| 30,000:1 (Dynamic) |
| Color Gamut72% NTSC (CIE1931) (Typ.) |
| Refresh Rate60 Hz |
| Viewing Angle178° (H)/178° (V) |
| Aspect Ratio16:9 |
| Surface Hardness |
| 9H (Pencil) |
| 7 (Mohs) |
| Surface GlassAnti-Glare & Anti-Fingerprint glass |
| Surface Haze25% Haze |
| Glass Bonding MethodZero Lamination |
| Display Area1895.04 × 1065.96 mm |
| Working Duration7 × 16 H |
| Transmittance88% ± 3 |
| Lifespan50,000 hours |
| Touch |
| TypeInfrared Touch Screen |
| Touch PointUp to 50-point multi-touch |
| Touch Response Time≤ 2 ms |
| Minimum Touch Object≥ 1.5 mm (≥ 90% touching area) |
| Touch Precision± 0.5 mm (≥ 90% touching area) |
| Touch Resolution32768 × 32768 |
| Built-in System |
| Operation SystemAndroid 14.0 |
| Memory8 GB (Optional 16 GB) + Max 16 GB Virtual RAM |
| Built-in Storage128 GB (Optional 256 GB) |
| ProcessorQuad-core Cortex-A76 × 4（2.4 GHz）and quad-core Cortex-A55 × 4（1.8 GHz） |
| GPUMali-G610 MC4 |
| HDCP Version2.3 & 2.0 & 1.4 |
| NPU6TOPs |
| Camera |
| Pixel48 MP for Photos & 8 MP for Video |
| Camera FunctionIntelligent switching between Android, OPS, and external PC systems. |
| Field Angle93.4° (diagonal), 84.5° (horizontal), 54.1° (vertical) |
| Distortion≤ 2.5% |
| Camera Resolution RatioUp to 4K |
| Microphone |
| SpecificationOmni-directional 8-array layout |
| Mic FunctionEcho reduction and smart noise-cancellation |
| Voice Distance12 m |
| Sampling Rate32 K |
| Mic Depth16 bit |
| Internal Function |
| LoudspeakerBuilt-in 2 × 20 W + 25 W loudspeaker; |
| Language SupportedSimplified Chinese, German, Italian, Arabic, Portuguese, Dutch, French, Indonesian, Thai, Vietnamese, Japanese, Spanish, English, Czech, Danish, Hungarian, Polish, Turkish, Russian, Romanian, Slovak, Korean, Uzbek, Bulgarian, Greek, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Hebrew, Ukrainian, Traditional Chinese (HK), Traditional Chinese (TW), Hindi, Latvian, Kazakh, Nepali |
| BluetoothBuilt-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.4 |
| NFC |
| Support card reader |
| 13.56 MHz, (ISO 14443A/ ISO 14443B/ ISO 15693) |
| Light SensorYes |
| Humidity and Temperature SensorRelative humidity accuracy: up to ± 1.5 %RH; Temperature accuracy: up to ± 0.1 °C |
| Image Processing TechnologySupport 3D digital noise reduction, face detection, automatic white balance, automatic purple fringing correction, automatic defogging, and shadow correction. |
| Audio Processing TechnologySupport dereverberation, adaptive noise reduction, adaptive non-stationary noise reduction, adaptive echo cancellation, automatic gain control, automatic electrical level control, sound source localization, speech dynamic detection, digital beam forming, speech detection. |
| AI FunctionAI Assistant, AI Identify, and AI Notes. Free for a 1-year validity period with 6,000 minutes for AI Notes. |
| WhiteboardBuilt-in whiteboard supports handwriting recognition, graphics recognition, document insertion, and more. |
| ScreenCastBuilt-in WonderCast software supports screen casting for up to 9 devices simultaneously. |
| Interface |
| Video & Audio Input |
| HDMI 2.1 TMDS × 3（Front x 1; Rear x 2; Support HDCP2.3 & 2.0 & 1.4; Support HDMI CEC protocol） |
| VGA × 1（Rear） |
| Audio × 1（Rear） |
| Video & audio output |
| HDMI 2.1 TMDS × 1（Rear） |
| Audio × 1（Rear） |
| SPDIF × 1（Rear） |
| Control interface |
| TOUCH-USB 3.0 × 1（Front × 1） |
| TOUCH-USB 2.0 × 2（Rear × 2） |
| RS232 × 1（Rear） |
| Network Interface |
| LAN (1000 Mbps) × 2（Rear） |
| Wi-Fi AP & Station, 2.4 G/5 G |
| Wi-Fi 6, IEEE 802.11 a/b/g/n/ac/ax 2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP |
| Data Transmission Interface |
| USB 3.0 × 4（Front × 2; Rear × 2） |
| USB 2.0 × 1（Rear） |
| Type-C × 2 (Front × 1; Rear × 1; Support USB 2.0, 100 W charging functions, DP IN 1.2 ) |
| Power |
| Power Supply100 to 240 VAC, 50/60 Hz |
| Standby Consumption≤ 0.5 W |
| Average Consumption< 274 W |
| Working Environment |
| Working Temperature0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity10%~90% RH |
| General |
| VESA800 mm × 600 mm (4 × M8-25 mm) |
| AccessoryWall mount bracket, hook, user manual, touch writing pen, packing list, 3 M touch USB cable, 3.5 M HDMI cable (2.0), 3 M power cable, remote control, screen cleaning cloth. |
| Package Dimensions (W × H × D)2157 × 1345 × 223 mm |
| Net Weight58.9 ± 0.5 kg |
| Gross Weight78.9 ± 0.5 kg |
| Product Dimensions （With Wall Attachment）1960.4 × 1173.7 × 106.4mm |
| Product Dimensions （Without Wall Attachment）1960.4 × 1173.7 × 82.4 mm |
