Dual-Radio Performance, Gigabit Speed Wi-Fi Solution
InterfaceInstallation
-
802.11ac
Wave2 -
Seamless
Layer 3 Roaming -
2x2
MU-MIMO -
Reyee Mesh
Technology -
Free Cloud
Management
-
802.11ac
Wave2 -
Seamless
Layer 3 Roaming -
2x2
MU-MIMO -
Reyee Mesh
Technology -
Free Cloud
Management
Better Multi-User Experience in High-Density Scenarios
Enjoy better performance with MU-MIMO technology under 802.11ac Wave2.
One Click to Optimize, Get Better Wi-Fi Experience
The WIO (Wi-Fi Intelligent Optimization) technology allows you to optimize wireless network by one click.
Easily Install Extra AP with Reyee Mesh
Less wiring, more relaxing.
Layer 3 Roaming, Smooth Transition
Roam smoothly between Layer 3 networks with non-interruption.
Easily Set Up Your Wi-Fi Network in 3 Minutes
With SON (Self-organizing Network) technology, easily set up a whole Wi-Fi network by Ruijie Cloud APP.
Cloud,
Make Your Business Easy
- Self-organizing network
- Centralized network management
- Scenario based configuration
- Cloud portal authentication
- Remote monitoring and maintenanc
|
Key Specifications |
|
|
Product Information |
|
|
Product Type |
|
|
Product Type |
Ceiling AP |
|
Hardware Specifications |
|
|
Wi-Fi Radio |
|
|
Radio design |
Dual-radio |
| 4 spatial streams | |
| ● 2.4 GHz: 2 x 2, MIMO | |
| ● 5 GHz: 2 x 2, MIMO | |
|
Maximum wireless data rate |
1266 Mbps |
|
6 GHz wireless data rate |
No |
|
5 GHz wireless data rate |
866 Mbps |
|
2.4 GHz wireless data rate |
400 Mbps |
|
Antenna |
|
|
Antenna |
2.4 GHz: 2 built-in omnidirectional antennas |
| 5 GHz: 2 built-in omnidirectional antennas | |
|
Dimensions and Weight |
|
|
Product dimensions (W x D x H) |
194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excluding the mounting bracket) |
|
Color |
White |
|
Weight |
≤ 0.45 kg (0.99 lbs.) (without packaging materials) |
|
Port Specifications |
|
|
Number of 10/100/1000BASE-T ports |
2 |
|
Power Supply and Consumption |
|
|
Power supply |
● DC power adapter |
| ● PoE/PoE+ | |
| Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred. | |
|
Local power supply |
Yes, one DC power connector (12 V, 1.5 A) |
|
Dimensions of the DC connector |
Outer diameter: 5.5 mm (0.22 in.) |
| Inner diameter: 2.1 mm (0.08 in.) | |
| Depth: 10 mm (0.39 in.) | |
|
PoE budget |
No |
|
Maximum power consumption |
12.95 W |
|
Environment and Reliability |
|
|
Operating temperature |
0°C to 40°C (32°F to 104°F) |
|
Mounting options |
Ceiling/Wall |
|
IP rating |
No |
|
Software Specifications |
|
|
WLAN |
|
|
Maximum number of associated wireless clients |
64 (2.4 GHz) |
| 110 (5 GHz) | |
| 110 (2.4 GHz and 5 GHz enabled) | |
|
Maximum number of devices that can be managed |
300 |
|
IP Service |
|
|
IPv6 |
Yes |
