Ruijie RG-RAP2200(F) Reyee Wi-Fi 5 1267Mbps Ceiling Access Point

Rs. 12,870

Dual-Radio Performance, Gigabit Speed Wi-Fi Solution

Better Multi-User Experience in High-Density Scenarios

Enjoy better performance with MU-MIMO technology under 802.11ac Wave2.

One Click to Optimize, Get Better Wi-Fi Experience

The WIO (Wi-Fi Intelligent Optimization) technology allows you to optimize wireless network by one click.

Layer 3 Roaming, Smooth Transition

Roam smoothly between Layer 3 networks with non-interruption.

Easily Set Up Your Wi-Fi Network in 3 Minutes

With SON (Self-organizing Network) technology, easily set up a whole Wi-Fi network by Ruijie Cloud APP.

Cloud,

Product Information
Product Type
Product Type	Ceiling AP
Hardware Specifications
Wi-Fi Radio
Radio design	Dual-radio
	4 spatial streams
	● 2.4 GHz: 2 x 2, MIMO
	● 5 GHz: 2 x 2, MIMO
Maximum wireless data rate	1266 Mbps
6 GHz wireless data rate	No
5 GHz wireless data rate	866 Mbps
2.4 GHz wireless data rate	400 Mbps
Antenna
Antenna	2.4 GHz: 2 built-in omnidirectional antennas
	5 GHz: 2 built-in omnidirectional antennas
Dimensions and Weight
Product dimensions (W x D x H)	194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) (excluding the mounting bracket)
Color	White
Weight	≤ 0.45 kg (0.99 lbs.) (without packaging materials)
Port Specifications
Number of 10/100BASE-T ports	2
Power Supply and Consumption
Power supply	● DC power adapter
	● PoE/PoE+
	Note: If both the DC power adapter and PoE/PoE+ are available for power supply, the DC power adapter is preferred.
Local power supply	Yes, one DC power connector (12 V, 1.5 A)
Dimensions of the DC connector	Outer diameter: 5.5 mm (0.22 in.)
	Inner diameter: 2.1 mm (0.08 in.)
	Depth: 10 mm (0.39 in.)
PoE budget	No
Maximum power consumption	12.95 W
Environment and Reliability
Operating temperature	0°C to 40°C (32°F to 104°F)

Mounting options	Ceiling/Wall
IP rating	No
